| Flow Ranges: |
1.5 – 2271 litres / minute |
| Wetted Parts: |
Brass, PVDF and Viton seals (optional Kalrez seals) |
| Port Size: |
¼” – 2″ Threaded, 3″ – 4″ ANSI 150# Flanged |
| Operating Pressure: |
20 bar (2″ and below), 13 bar (3″ & 4″) |
| Temperature: |
+2 to +100°C |
| Accuracy: |
±2% of full scale flow |
| Features: |
- Flow transmitter 4-20 mA
- Optional temperature transmitter for 3/4 – 4 inch units
- Pulse out for totalization
- LED digital display
- User configurable alarm set points
- No moving parts to clog or wear
- Selectable Engineering units
- Selectable alarm state
- Flow direction
- Rotatable control box and display
|
