| Applications: |
Low cost meter for liquids and gases. Can be supplied with various float and seal materials to suit a great number of liquid and chemical solutions. |
| Flow Range: |
4 l/h to 1 000 l/h (water) |
| Accuracy: |
±4.5% FS |
| Connection: |
1/2″ to 3″ PVC threaded |
| Length: |
232 to 260 mm |
| Materials: |
| Metering Tube: |
Trogamid T |
| Connectors: |
PVC, SS-316L |
| Float: |
SS-316L, PVC, PVDF |
|
| Scale: |
10:1 |
| Pressure: |
8 to 15 bar |
| Temperature: |
-10ºC to +60ºC |
| Alarms: |
Reed switches |
| Transmitter: |
0…4-20mA (10 point resolution) |
|
